Haulotte 5533A Towable Man Lift 55′
The Haulotte 5533A is a powerful, towable articulated boom lift designed for professionals who need extended reach and quick setup. With a 61′ working height, 33′ outreach, and self-leveling outriggers, it delivers safe, efficient access to high or hard-to-reach areas—all without the need for a commercial driver’s license.
Starting at $300.00
Description
The Haulotte 5533A 55′ Towable Man Lift was designed to be fast, efficient, and user-friendly. Both the platform and ground controls feature a clear display panel with simple, easy-to-read buttons surrounding a machine diagram—making operation straightforward, even for first-time users.
This articulated boom lift is powered by four rechargeable 6V deep-cycle batteries, providing reliable, quiet, and emission-free operation for a full day’s work. It can also be plugged in for charging or continuous power when needed.
To support all your on-the-job needs, the lift includes a built-in 110V GFI-protected power outlet, air line, and water line directly in the platform—so you can plug in power tools or cleaning equipment without hassle.
The lift reaches a working height of 61′ 3″, with a platform height of 55′ 3″ and an impressive horizontal outreach of 33′ 5″. With its self-leveling hydraulic outriggers, setup is quick and stable, even on uneven ground—leveling on slopes up to 12.5° automatically in under 30 seconds.
After a quick demo, most users feel confident operating the machine. The Haulotte 5533A can be towed easily by any ½-ton vehicle with a Class III hitch and 2″ ball. A safety harness and lanyard are also available for fall protection and compliance on elevated jobs.
Both in store pickup and delivery services are available for all rentals.
Delivery rates for single truck/trailer rentals are as follows:
- For delivery times of 1-44 min: $85 round trip ($42.50 each way)
- For delivery times of 45-75 min: $125 round trip ($62.60 each way)
Delivery rates for dual load truck/trailer rentals are as follows:
- For delivery times of 1-44 min: $125 round trip ($62.50 each way)
- For delivery times of 45-75 min: $200 round trip ($100 each way)
For delivery times exceeding 75 minutes for either single or dual loads, call for a custom quote!
Product Applications
- Tree trimming
- Power washing
- Roofing
- Lighting
- Painting
- Signs
- Gutters
- Siding
Product Features
- Self-leveling hydraulic outriggers for fast, stable setup
- Spacious 2-person platform with 500 lb capacity and onboard 110V, air, and water lines
- Battery-powered electric system for quiet, emission-free operation
- Towable trailer-mounted design — no CDL required
- Intuitive ground and platform controls with pad-lockable cover for security
Product Specifications
| Working Height | 61 ft 3 in |
| Platform Height | 55 ft 3 in |
| Horizontal Outreach | 33 ft 5 in |
| Lift Capacity | 500 lbs |
| Platform Size | 4'1" x 2'9" |
| Length | 23 ft 8 in |
| Width | 5 ft 7 in |
| Stowing Dimensions | 23'8" x 5'7" x 6'9" (LxWxH) |
Knowledge Base: View This Machine In Action
